Ajax LightCore (2-way) — Relay module of the Ajax LightSwitch for two-way switching of one lighting circuit, without a neutral wire.
Key features
- For 2-way switch circuits
- Single channel, 5–600 W
- Works on live wire only, no neutral
- Overcurrent and overheat protection
- Combine with a 1-gang/2-way touch button
Specifications
| Product line | Comfort & automation · Jeweller wireless |
|---|
| Load | 1 channel, 5–600 W, 230 V |
|---|
| Installation | Wall box under 55 mm frame system, no neutral needed |
|---|
| Communication | Jeweller, two-way, encrypted |
|---|
| Range | Up to 1,100 m to hub or range extender (open space) |
|---|
| Safety | IP20; overcurrent (2.6 A) and overheat protection |
|---|
Requires an Ajax hub. Ajax article 45112.142.NC · Code AJ-LIGHTCORE-2WAY
